IQBOARD Document Camera

Features

• 4K Cam & 10x Optical Zoom
• Extra Large Coverage
• Easy Connectivity for Display
• Dual Image Output
• Matrix Switch
• Extremely Compact Design
• Interactive Whiteboard Access

Specifications

• Model: E4521
• Resolution: 8.0MP
• Sensor Pixel: 1/2.8" Sony CMOS
• Frame Rate: 30fps
• Zoom: 10x Optical Zoom, 10x Digital Zoom
• Focus: Automatic / Manual
• Shooting Range: A3
• Device Structure: Folding, supports multi-angle shooting; lens rotates 90° left and right
• HDMI Output: 4K, 1080P
• VGA Output: 1080P
• Record Output: 3840×2160P@20fps (Max), 1080P@30fps
• USB Output: 3840×2160@15fps, 1080P@30fps
• Image Adjustment: Brightness, sharpness, contrast, saturation
• Image Trick: Freeze, Mirror, B&W/Color, Text, Image, On-Screen Contrast, Picture-in-Picture, etc.
• LED Light: 3-level adjustment
• Interface: VGA (Input×1 & Output×1), HDMI (Input×1 & Output×1), USB×1, USB Mouse
• TF Card Storage: Supports up to 32G
• Native Annotation Function (by mouse operation): Real-time annotation, auto focus, zoom in/out, photo, video, playback, on-screen comparison, picture-in-picture, freeze, title freeze, rotate, image, text, and more
• Buttons: Power,Switch,Rotate,Light,Zoom In&Out,Brightness Up&Down,AF
• Infrared Remote Control: Yes
• MIC: Yes
• Power Supply: DC 12V
• Size (Folded): 373.5×110×160mm
• Size (Expanded): 448×385×160mm
• Weight: 2.8kg
