SHARP UN-series 553S Display

SHARP Ultimate Ultra Narrow series, 0.88mm content-to-content. Recommended for 24/7 operation. Note does not include a Remote Control. Video Wall solution best purchased with a KT-RC3 Remote & Sensor Kit.

Features

• Easy installation – effortlessly set up your wall display with Auto TileMatrix and out-of-the-box calibrations. Save time by plugging in ready-to-use image presets for predefined application scenarios.
• Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
• Lifelike and consistent colour – expect colour reproduction that feels true to life with IPS panel technology, the top choice when it comes to colour consistency. The S-IPS panel ensures that perfect visibility is maintained in landscape and portrait mode and at extreme viewing angles as viewers pass by.
• Secure reliability and longevity of video walls – a unique NEC heat management system enables the user to monitor and control the heat inside the display.
• Cost saving device management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.

Specifications

General Information

• Panel Technology: IPS with Direct LED backlights
• Screen Size: 55 inch
• Aspect Ratio: 16:9
• Max. Brightness (average): 700 cd/m²
• Contrast Ratio: > 3500:1
• Viewing Angle (H/V): 178° / 178° (typ. at CR 10:1)
• Colour Gamut: 72% of NTSC
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape; Portrait

Resolution

• Native Resolution: 1920 × 1080
• Supported Resolutions: 640 × 480; 720p (50/60 Hz); 800 × 600; 1024 × 768; 1080i; 1080p; 1280 × 768; 1280 × 1024; 1360 × 768; 1600 × 1200; 1920 × 1080; 3840 × 2160

Synchronisation Rate

• Horizontal Frequency: 26–134 kHz
• Vertical Frequency: 23–86 Hz

Connectivity

• Input Video Analogue: 1 × VGA; Composite (RCA)
• Input Video Digital: 1 × DVI‑D (HDCP); 1 × OPS Slot; 2 × DisplayPort (HDCP); 2 × HDMI (HDCP)
• Input Audio Analogue: 2 × 3.5 mm jack
• Input Audio Digital: 2 × DisplayPort; 2 × HDMI
• Input Control: 1 × Remote Control (3.5 mm jack); 1 × RS‑232; 2 × LAN 100 Mbit
• Input Data: 1 × microSD (MediaPlayer); 1 × USB 1.0 (Downstream); 1 × USB 1.0 (MediaPlayer); 1 × USB 2.0 (Upstream); 2 × USB 1.0 (Compute Module, 1 × 5V/2A powered)
• Output Video Digital: 1 × DisplayPort (loop through: DisplayPort, OPS slot‑in PC); 1 × HDMI (loop through: HDMI, OPS slot‑in PC, MediaPlayer)
• Output Audio Analogue: 1 × 3.5 mm jack
• Output Control: LAN 100 Mbit

Calibration

• Factory Calibration: Gamma; Intensity; RGB; Uniformity; White Point
• Sensor Calibration (USB): PC‑less calibration with USB Sensor MDSVSensor3; White Copy (post self‑calibration)
• Calibration with Software: Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; Update Uniformity Correction; White Point
• Calibration Software: Display Wall Calibrator

Open Modular Intelligence

• OPS Slot: Open Pluggable Specification (NEC / Intel OPS standard)
• OPS Max. Current / Power Consumption: 3.6 A / 58 W

Sensors

• Human Sensor: Optional, external, 4–5 m range, triggered actions programmable
• Temperature Sensor: Integrated, 3 sensors, triggered actions programmable
• NFC Sensor: Integrated, 2 cm range, requires free NEC Android App

Electrical

• Power Consumption: 180 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Operating Hours: 24/7

Environmental

• Operating Temperature: 0°C to 40°C
• Operating Humidity: 20% to 80%
• Storage Temperature: -20°C to 60°C
• Storage Humidity: 10% to 90%

Mechanical

• Weight: 28.1 kg
• Bezel Width: 0.44 mm (top/left); 0.44 mm (bottom/right); 0.88 mm total
• Dimensions (W × H × D): 1,210.5 × 681.3 × 103 mm
• VESA Mounting: 400 × 400 mm (FDMI); 4 × M6

Available Options

• Accessories: Calibration kit (KT‑LFD‑CC2); Overframe kit (KT‑55UN‑OF5); Remote control kit (KT‑RC3)
• OPS Slot: Intel® Atom, Celeron, Core i3, i5, i7 Slot‑in PCs

Green Features

• Energy Efficiency: Carbon savings meter; Energy consumption 146 kWh/1000 h; Class G; Human sensor; LED backlight

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK) up to 5000 × 5000; PNG (interlace, alpha) up to 4000 × 4000
• Supported Video Formats: MP4 / MOV / FLV (H.264 video, MP3/AAC audio) up to 1080p@30 Hz, 1080i@60 Hz; MPG (mpeg1/2 video, mpeg audio layer2/3, AAC‑LC); WMV (H.264, WMV advanced L3, WMV simple/main; MP3/WMV audio)
• Supported Audio Formats: MP3 up to 320 kbit/s; WAV (LPCM) up to 48 kHz

Other Features

• Safety and Ergonomics: BSMI; CE; EAC; EMC Class B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C‑UL; VCCI
• Pixel Failure Class: ISO 9241‑307, Class 2
• Special Characteristics: Auto ID assignment; Auto tiling; Automatic Alarm E‑Mails; DICOM Simulation; Frame Comp; HTTP Server; Image Flip; NaViSet Administrator 2; PJLink Support; TileMatrix; USB Media Player; User input priority; User readable logs
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio (Speakers): Optional Speakers (15 W + 15 W)
• Shipping Content: Display; DisplayPort Cable; HDMI Cable; LAN Cable (RJ45); Power Cable
